350W AC DC Open Frame Medical Power Supply with PFC function single output

350W AC DC Open Frame Medical Power Supply with PFC function single output

Descriptions

LOF350-20Bxx -C series is one of Mornsun’s open frame AC-DC switching power supply and suitable for all kinds of BF type (be accessible to patients) medical systemequipment.It features universal AC input and at the same time accepts DC input voltage,cost-effective,built-in active PFC function,high efficiency and high reliability.These converters offer excellent EMC performance and meet IEC/EN/UL62368, GB4943,IEC/EN60335,IEC/EN61558,IEC/EN/ES60601 standards and they are widely used in areas of Plant lighting,security,telecommunications,medical etc.

Features

• l Universal 90 - 264VAC or 127 - 370VDC input voltage
• l Accepts AC or DC input (dual-use of same terminal)
• l Operating ambient temperature range: -40℃ to +70℃
• l Built-in active PFC function
• l Extremely low leakage current＜0.1mA
• l Stand-by power consumption＜1.0W
• l The base plate with conformal coating
• l Output short circuit, over-current, over-voltage protection, over-temperature protection
• l Suitable for BF application
• l Operating altitude up to 5000m

​Specifications
