| Rated Power 460W |
Input | 90V-264VAC(47Hz-63Hz) 4A Max | |||
| Output | Load Range | Voltage | Ripple & Noise | ||
| Min | Max | ||||
| +5V | 0.5A | 20A | ±5% | ≤50mV | |
| +12V | 1A | 38A | ±5% | ≤120mV | |
| +5VSB | 0.1A | 3A | ±5% | ≤50mV | |
| +3.3V | 0.5A | 15A | ±5% | ≤50mV | |
| -12V | 0A | 0.5A | ±5% | ≤120mV | |
| Not exceeding 140W if combines +3.3V and 5V together | |||||
| Standby Power Consumption | ≤3W | ||||
| Protective Function | Overvoltage protection, over power protection, short circuit protection, | ||||
| Working Environment | Air Temperature:0~50℃,Relative Humidity:5%~85% without condensation | ||||
| Storage Environment | Air Temperature:-40~55℃,Relative Humidity:5%~95% | ||||
| EMI | Conform EN55022 Class B GB9254 Class B | ||||
| Earth Leakage Current | ≤0.5mA(264VAC/50Hz) | ||||
| MTBF Value | ≥100K hours.MIL-HDBK-217F(25℃) | ||||
| Cooling Method | Forced cooling and dual ball fan cooling method | ||||
| Package Method | 10PCS/Per Case | ||||
| Typical Dimensions(mm) | 215(L)×100(W)×40(H) | ||||
| Design Standards | Conform SSI 1U 2.93Industrial server power supply standards | ||||
| Application | Network Server, IPC , etc. | ||||
