| Rated Power 250W |
Input | 90-265VAC(47Hz-63Hz) 3A Max | |||
| Output | Load Range | Voltage | Ripple & Noise | ||
| Min | Max | ||||
| +5V | 0.3A | 14A | ±5% | ≤50mV | |
| +12V | 1A | 14A | ±5% | ≤120mV | |
| +5VSB | 0A | 2A | ±5% | ≤50mV | |
| +3.3V | 0.5A | 12A | ±5% | ≤50mV | |
| -12V | 0A | 0.3A | ±10% | ≤150mV | |
| Not exceeding 80W if combines +3.3V and 5V together | |||||
| Standby Power Consumption | ≤3W | ||||
| Protective Function | Overvoltage protection,over power protection, over temperature protection, short circuit protection | ||||
| Working Environment | Air Temperature:0~45℃,Relative Humidity:5%~85% without condensation | ||||
| Storage Environment | Air Temperature:-40~70℃,Relative Humidity:5%~95% | ||||
| EMI | Conform EN55022 Class B GB9254 Class B | ||||
| Earth Leakage Current | ≤1.75mA(264VAC/50Hz) | ||||
| MTBF Value | ≥100K hours.MIL-HDBK-217F(25℃) | ||||
| Cooling Method | Forced cooling and dual ball fan cooling method | ||||
| Package Method | 20PCS/Per Case | ||||
| Typical Dimensions(mm) | 150(L)×80(W)×40(H) | ||||
| Design Standards | Conform Intel Flex 12V 1.0 standards | ||||
| Application | Routers, AIO, advertising machines, etc. | ||||
