| Rated Power 800W |
Input | 90V-264VAC(47Hz-63Hz) 10A Max | |||
| Output | Load Range | Voltage | Ripple & Noise | ||
| Min | Max | ||||
| +12.11V | 1A | 65A | ±5% | ≤120mV | |
| +12VSB | 0.1A | 3A | ±5% | ≤120mV | |
| Support N+1(0≤N≤3)Redundant applications and hot swap | |||||
| Standby Power Consumption | ≤5W | ||||
| Protective Function | Overvoltage protection, over power protection, over temperature protection, short circuit protection, | ||||
| Working Environment | Air Temperature:0℃~55℃,Relative Humidity:0%~95% without condensation | ||||
| Storage Environment | Air Temperature:-20℃~70℃,Relative Humidity:0%~95% | ||||
| EMI | Conform EN55032 Class A GB9254 Class A | ||||
| Earth Leakage Current | ≤3.5mA(240VAC/50Hz) | ||||
| MTBF Value | ≥50000 hours.(45℃,230VAC,80% load) | ||||
| Cooling Method | Forced cooling and fan cooling method | ||||
| Package Method | 8PCS/Per Case | ||||
| Typical Dimensions(mm) | 185(L)×73.5(W)×40(H) | ||||
| Design Standards | Conform CRPS redundant power supply standards and PMBus 1.2 specification | ||||
| Application | Network Server, IPC, etc. | ||||
