| rated power: | 2200W | |||||
| input voltage: | 11.4-12.6Vdc | |||||
| input current: | ≤14A | |||||
| output voltage: | 12V1 | 12V2 | 5V | 3.3V | 5VSB | -12V |
| output current: | 145A | 108A | 50A | 24A | 3A | 0.5A |
| voltage regulation accuracy: | ≤±5% | |||||
| ripple and noise: | ≤120mVp-p | |||||
| efficiency: | ≥94% | |||||
| communication: | I²C | |||||
| protection: | output overvoltage, output undervoltage, output overcurrent, output short circuit, over temperature protection | |||||
| working environment: | air temperature: 0-55℃, Relative Humidity: 5%-95% without condensation | |||||
| storage environment: | air temperature: -40-70℃, Relative Humidity: 5%-100% | |||||
| EMI: | EN55022 Class A | |||||
| IP rating: | IP20 | |||||
| cooling method: | forced air cooling | |||||
| dimension: | 265*77*84mm | |||||
| application field: | server | |||||
