| Rated Power 300W |
Input | 90V-264VAC(47Hz-63Hz) 5A Max | |||
| Output | Load Range | Voltage | Ripple & Noise | ||
| Min | Max | ||||
| +5V | 0.3A | 13A | ±5% | ≤50mV | |
| +12V1 | 0.2A | 20A | ±5% | ≤120mV | |
| +5VSB | 0.1A | 2A | ±5% | ≤50mV | |
| +3.3V | 0.3A | 10A | ±5% | ≤50mV | |
| -12V | 0A | 0.3A | ±10% | ≤120mV | |
| Not exceeding 90W if combines +3.3V and +5V together | |||||
| Standby Power Consumption | ≤3W | ||||
| Protective Function | Overvoltage protection, over power protection, short circuit protection, | ||||
| Working Environment | Air Temperature:-10~60℃,Relative Humidity:5%~85% without condensation | ||||
| Storage Environment | Air Temperature:-40~70℃,Relative Humidity:5%~95% | ||||
| EMI | Complies with EN55022 Class B GB9254 Class B | ||||
| Earth Leakage Current | ≤3.5mA(264VAC/50Hz) | ||||
| MTBF Value | ≥100K hours.MIL-HDBK-217F(25℃) | ||||
| Cooling Method | Forced cooling and fan cooling method | ||||
| Package Method | 10PCS/Per Case | ||||
| Typical Dimensions(mm) | 140(L)×150(W)×86(H) | ||||
| Application | IPC, etc. | ||||
