| Model | HKI350-240PB | HKI350-480PB | |
| Output | direct voltage/current | 24V/14.6A | 48V/7.3A |
| voltage range | 21.6~26.4V | 43.2~52.8V | |
| current range | 0~14.6A | 0~7.3A | |
| stabilized voltage precision | ±2% | ±2% | |
| ripple | ＜100mVp-p | ＜150mVp-p | |
| Input | least efficiency | 86% | 86% |
| voltage range | 90～264VAC；102~370VDC | ||
| surge current | Cold-boot＜60A/230VAC | ||
| Protection | overvoltage | 115%-135%(rated voltage),re-power after fault removed | 115%-135%(rated voltage),Auto restart after fault removed |
| overcurrent | 120%-180%(rated current),re-power after fault removed | ||
| over temperature | OTP point to ensure that all components do not exceed the specified temperature,re-power after fault removed | ||
| undervoltage | AC input undervoltage protection point: <=60Vac, undervoltage protection recovery point: >=70Vac | ||
| short circuit | When the output terminal is short-circuited, the power supply cannot be damaged, cannot catch fire, and can automatically recover after the short-circuit is eliminated | ||
| Environment | operating temperature | -30～+70℃,20～90﹪RH,no condensation(please refer to derating curve) | |
| reserving temperature | -40～+85℃,10～95﹪RH,no condensation | ||
| vibration | 10～500HZ,5G 10 min/cycle,60 min/X,Y,Z directions | ||
| Safety | safety standard | GB4943 EN62368 | |
| electromagnetic compatibility standard | EN55032 Class B, GB9254 Class B,EN61000-4-2,3,4,5,6,8,11 , EN61000-3-2,3 | ||
| Withstand voltage | I/P-O/P:3KVAC I/P-FG: 2KVAC O/P-FG: 0.5KVAC | ||
| Other | dimensions | 215*115*30mm | |
| package | 20pcs/18kg | ||
