| Model | HKI250-315PB | ||
| Output | direct voltage/current | 5V/4A, 15V/10.5A,-15V/4A | |
| voltage adjustment range | 4.75~5.25V, 14.25~15.75V, 14.25~15.75V | ||
| current adjustment range | 0.1~4A, 0.1~10.5A, 0.4~4A | ||
| stabilized voltage precision | ±3% | ||
| ripple | ＜50mVp-p(5V), ＜150mVp-p(15V), 150mVp-p(-15V) | ||
| Input | least efficiency | 80% | |
| voltage range | 90~264VAC | ||
| surge current | Cold-boot＜60A/230VAC | ||
| Protection | overload | 170W-200W(15V),80W-120W(5V&-15V) | |
| overvoltage | 5.5V-7V(5V),16.5V-19.5V(15V),16.5V-19.5V(-15V) | ||
| short circuit | When the output terminal is short-circuited, the power supply cannot be damaged, cannot catch fire, and can automatically recover after the short-circuit is eliminated | ||
| Environment | operating temperature | -20～+50℃,10～85﹪RH, No condensation(please refer to derating curve) | |
| reserving temperature | -40～+70℃,10～90﹪RH,No condensation | ||
| vibration | 10～500HZ,5G 10 min/cycle,60 min/X,Y,Z directions | ||
| Safety | safety standard | GB4943,IEC60950-1 approved | |
| electromagnetic compatibility standard | EN55022 Class A, GB9254 Class A,EN61000-4-2,3,4,5,6,8,11 , EN61000-3-2,3 | ||
| Withstand voltage | I/P-O/P:3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | ||
| Other | dimensions | 215*115*30mm | |
| package | 16pcs/13kg | ||
