| Model | HDZ1502-3C | |
| Output | direct voltage/current | 12V/6A,24V/3.25A |
| voltage range | 11.4~12.6V, 22.8~25.2V | |
| current range | 0.5~3.25A, 0.5~6A | |
| stabilized voltage precision | ±3% | |
| ripple | ＜120mVp-p(12V), ＜240mVp-p(24V) | |
| Input | least efficiency | 80% |
| voltage range | 90~264VAC | |
| surge current | Cold-boot＜50A/230VAC | |
| Protection | overload | 110-175W(90-132VACInput),165-225W(180-264VACInput) |
| overvoltage | 13.2V-18V(12VOutput路),26.4V-36V(24VOutput路) | |
| short circuit | When the output terminal is short-circuited, the power supply cannot be damaged, cannot catch fire, and can automatically recover after the short-circuit is eliminated | |
| Environment | operating temperature | -25～+40℃,5～90﹪RH,no condensation(please refer to derating curve) |
| reserving temperature | -40～+70℃,5～95﹪RH,no condensation | |
| vibration | 10～500HZ,5G 10 min/cycle,60 min/X,Y,Z directions | |
| Safety | safety standard | GB4943, IEC60950-1 approved |
| electromagnetic compatibility standard | EN55022 Class A, GB9254 Class A,EN61000-4-2,3,4,5,6,8,11 , EN61000-3-2,3 | |
| Withstand voltage | I/P-O/P:3KVAC I/P-FG: 1.5KVAC O/P-FG: 0.5KVAC | |
| Other | dimensions | 159*97*30mm |
| package | 21pcs/13kg |
|
